LARS® ACL are indicated for patient suffering from acute or chronic injury of anterior cruciate ligaments. The ligaments consist of two distinct sections: free longitudinal intra-articular fibers to reduce wear and fatigue during torsion and intra-osseous section, providing resistance to wave loosening and elongation.
We offer a comprehensive range of ligaments size to accommodate varying patients’ anatomy. Each type of ligament contains a specific number and length of fibers, depending on indications.
The surgeon must select the appropriate LARS® ligament size based on the patient’s profile and preferences. We offer a range of fixations (screws and staples) and instruments compatible with these references’ sizes.
Available in different sizes
covering different patient populations and varying anatomy
Available in different designs
single bundle, available in tubular shape for reinforcement with autograft, suitable for different surgical techniques, designed to resist traction with different strength
Patented longitudinal free fibers
mimic the natural ligament and minimize fatigue during torsion
Available off-the-shelf instruments
with superior quality of targeting device for precision, with recognized surgical techniques focusing on the isometric position of the tunnel.
Compatible with LARS® titanium screws
non-edeged screw to ease the insertion and provide strong fixation without creating any damage to the ligament
LARS® ligaments are implantable and non-absorbable medical devices. They are made of Polyethylene Terephthalate (PET) fabrics composed of adjacent technical threads, cross-linked by a mesh that holds the structure together.
LARS® cannulated ligament screws are made of Titanium Alloym corrding to ISO 5832-3 standard.
LARS® staples are made of Cobalt Chromium Alloy, according to ISO5832-4 standard.
For Reconstruction & Reinforcement of Anterior Cruciate Ligament
L020801 – AC 80 L
L020802 – AC 80 R
L021001 – AC 100 2BL
L021002 – AC 100 2BR
L021201 – AC 120 2BL
L021202 – AC 120 2BR
SCREW:
FST110725 – Ø 7 mm x 25 mm
FST110730 – Ø 7 mm x 30 mm
FST110825 – Ø 8 mm x 25 mm
FST110830 – Ø 8 mm x 30 mm
FST110925 – Ø 9 mm x 25 mm
FST110930 – Ø 9 mm x 30 mm
FST111030 – Ø 10 mm x 30 mm
STAPLES:
GST200820 – 8 mm x 20 mm
GST201020 – 10 mm x 20 mm
AVM01 – ACL target device
C26001 – ACL femoral hook
C26002 – ACL tibial hook
C26003 – K-wire guide
U01009 – K-wire guide double trocar
U01015 – K-wire single trocar 250mm
U01254 – Wire loop guide 300mm
U01401 – Wire-loop, 10 units
U02456 – Ligament traction handle
U01018 – K-wire blunt tips 330mm
U01304 – Soft tissue protector
ATVS35 – Hexagonal cannulated screwdriver
ACPL02 – Ligament cutter
U01153 – Cannulated drill bit 7 mm
U01154 – Cannulated drill bit 7.5 mm
U01157 – Cannulated drill bit 8 mm
Additional instruments
AIAG01 – Staple holder Optional Optional
AEAG01 – Staple extractor Optional Optional
U01160 – Cannulated drill bit 11 mm
U01161 – Cannulated drill bit 12 mm
U01155 – Cannulated drill bit 9 mm
U01158 – Cannulated drill bit 10 mm
